Rakinda F2-TH Android System 8inch Screen Facial Recognition Device Biometric Time Attendance
Rakinda F2-TH face recognition temperature measurement tablet is embedded type certification device based on Android system. F2-TH supports the face temperature measurement function, which can quickly and accurately test the body temperature and give an alarm when detecting high temperature. It is suitable for office areas, hotel gates, office buildings, schools, shops, communities, public services and management projects.
It supports 1280P HD cameras, speakers, COM ports and TCP / IP communication methods, supports external ID SD card readers, QR code readers and ID card readers and supports multiple identity authentication methods, which can be used in conjunction with personnel channel to facilitate personnel access management.
Product Parameters:
| Face Recognition Terminal Product Parameters | |||
| Screen | Size | 8", full viewing angle, 170° IPS LCD | |
| Resolution | 800*1280 | ||
| Camera | Type | RGB | TOF |
| Resolution (horizontal × vertical) | Support 1080P/960P/720P/VGA | 640× 480 Pixel | |
| Field of view (horizontal × vertical) | 74° × 56° @960P (Default) | 80° × 60° | |
| 63° × 37° @1080P | |||
| 74° × 42° @720P | |||
| 74° × 56° @VGA | |||
| Frame rate (FPS) | Maximum 30FPS @960P/720P/VGA Up to 15FPS @1080P | MAX 30FPS | |
| Detection distance (unit: meter) | 0.35-1.2 | ||
| light source | 850nm VCSEL | ||
| Working temperature (degree Celsius °C) | 0℃-50℃ | ||
| Core parameter | CPU | 6 cores, clocked at 2.0GHz | |
| RAM | 2G | ||
| ROM | 16G | ||
| OS | Android 7.1.2 | ||
| Parts | Fill light | Infrared, LED fill light | |
| Network module | Support wired, wireless (2.4GWi-Fi), wireless (USB external) | ||
| Bluetooth Module | 4.0 | ||
| 4G communication module | Optional (built-in or external) | ||
| ID card reader | Optional (built-in or external) | ||
| GPS | Optional (built-in or external) | ||
| Port | USB | USB2.0 1 | |
| RD232 | RS232 serial port, 2.5mm terminal block 2P | ||
| Relay output | 2.5mm terminal block 3P | ||
| Wiegand interface | 2.5mm terminal block 3P, support Wiegand 26 | ||
| Wired network interface | RJ45 Gigabit network | ||
| General parameters | IP Protection | IP54 | |
| Power | DC12V (±10%) /3A | ||
| Operating temperature | -20℃ ～70℃ | ||
| Working humidity | 10%～90 % | ||
| Power consumption | 22W MAX | ||
| Installation method | Wall bracket installation, gate bracket installation | ||
| Equipment size | 39cm x 12cm x 9cm | ||
| Weight | 2.5kg | ||
