1D 2D QR Code IP64 Wiegand 34 Access Control System
Smart Card Door Access Control Product Description
The product has Wiegand 26/ 34 output when the product is used as a 2d code reader, which can make the traditional access control, lift control, yard products,own the 2d code access function immediately without changing the main controller.
And can access legally when it must comply with the rules of the 2d code so that the traditional access control, lift control and yard products have a real CPU system security level at once and reduce system costs greatly.
Product Features of Gate Access Control System
1. Single-door access control + 2d code scanner engine + the second generation ID card reader
2. Network IP parameters, lock delay, Wiegand 26/34
3. Data memory and the ferroelectric memory
4. RJ45 10 / 100M TCP / IP transmission,WIFI transmission or mobile phone Bluetooth transmission,Supports TCP/IP remote IAP upgrade.
5. Built-in dual hardware anti-crash watchdog
6. Docking DEMO Language: JAVA, C#, C++, etc.
QR Code Access Control Devices Parameters:
| 2D Code Engine Component Parameters | |
| Image Sensor | 752X480 |
| Light Source | White LED |
| Symbologies | 2D: PDF417, QR CODE, DATA MATRIX, Support reading screen and printed code |
| 1D: CODE 128, UCC/EAN-128, AIM-128, EAN-8 etc. | |
| Reading Distance | 10-55mm |
| Scan Angle | 360° Full Angle |
| Input and Output Parameters | |
| Power Input | 9-18VDC |
| Working Current | < 600mA |
| Can read like ISO14443Aor ISO14443B card serial number | Such as second-generation ID card, FM1208 CPU card, M1 card (Mifare S50, Mifare S70 IC card), SRIX4K, etc. |
| Barcode or 2D code input | Wiegand 26/ 34 output, output IC card number (common read head function) and associated card number output in compliance with QR code reservation rules |
| Communication Interface | RJ45 10/100M TCP/IP, Extensible Wireless WIFI, Bluetooth |
| Communication Protocol | Support TCP / UDP / HTTP |
| Voice output | comes with voice, amplifier and speaker output, nearly 150 kinds of voice output, customizable voice |
| Device input | 12V DC power input, 1 line gate input, 1 line exit button input, 1 line alarm input |
| Equipment output | 2 way 250V/5A relay output, 1 way unlock, 1 way expansion can control door opener, light, water valve, etc. |
| Wiegand output | Wiegand 26/34 output |
| Dimensions | |
| Installation size | 152mm * 85mm * 35mm (L*W*H), Compatible with standard 86 box |
Application Scenario of RFID QR Access Contro System
Access control device has TCP/IP Ethernet port wiegand 26/34bits interface,which can read QR and mifare card both to get access,bluetooth and wif is optional.I is widely used in house buliding,official building,GYM and so on.
FAQ
Q1: Can I get some samples? Are they free?
A1: We support 1pc sample order. Samples should be paid.
Q2: How can I buy?
A2: Pls contact us first according to the contact info. We will send you proper link directly.
Q3: What is your payment method?
A3: We accept PayPal ,T /T, LC, Western Union , MoneyGram.
Q4: How long is your warranty time?
A4: Our officially promised warranty time is two years after delivery.
Q5: Can you provide OEM service?
A7: Yes. We need further discuss about details.
